Application
- Small fountains. Civil applications, solarheater systems, Residentialbungalows, Drinking water supply Gardens and Domestic, Small gardens, Water circulationin lawns Waterstorage tanks, Smalifarms.Domestic pressure boosting
Features
- Corrosion free SS Casing, SS Shaft and brass impeller
- Available in cast iron and aluminium extrusion body.
- Double sealed ball bearing
- Sturdy handle for easy lifting
- Specifications
- Material of construction
- Product Detail
| Power Range | : | 0.37 kW to 0.75 kW (0.5 HP t0 1.O HP) |
| Versions | : | 1 Phase, 180 Volts to 240 volts, 50 Hz, AC supply |
| Speed | : | 2880 rpm |
| Direction of Rotation | : | Clockwise from the driving end |
| Nominal size (Suc x Del) | : | 25 x 25 mm |
| Class of Insulation | : | B |
| Type of Duty | : | S1 |
| Part Name | Material |
|---|---|
| Pump Casting | Stainless Steel (Non Magnetic) |
| Motor Frame | Aluminium & C.I. |
| Impeller | Brass |
| Shaft | SS 410 |
| Sealing | Mechanical Seal (Carbon & Ceramic) |
| Model | Kw / Hp | Pipe Size In mm |
Body | Head In Meters / Discharge In LPH | Frame Size | Price |
|||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 6 | 9 | 12 | 15 | 18 | 21 | 24 | 27 | 30 | 33 | 36 | 39 | 40 | 42 | ||||||
| V-Star 2 CI | 0.37 / 0.50 | 25 * 25 | CI | 2270 | 2090 | 1910 | 1800 | 1700 | 1550 | 1300 | 1120 | 940 | 780 | 650 | 440 | 300 | 180 | 71 | 4298 |
| V-Star 2 CI | 0.37 / 0.50 | 25 * 25 | CI | 2270 | 2090 | 1910 | 1800 | 1700 | 1550 | 1300 | 1120 | 940 | 780 | 650 | 440 | 300 | 180 | 71 | 4225 |
